，Contractual
Use，
The PROLED PIXEL CONTROLLER PRO is designed to control Digital Flex Strips with WS2811, WS2812,
WS2813, WS2814, WS2815, WS2818B, UCS2904, P943, GS8208 and SK6822 LED-Chips. Up to 11.111
pixel can be controlled by build in programs. Additionally the LED-Pixel can be controlled by DM.
Because of six data lines, you can control very long line. By choosing of different configurations – 6 lines
continuously, copied or mirrored – as well as MONO, RGB or single pixel control, you have various possibility
of usage. Preinstalled programs or self-made settings allow to use the controller as an stand-alone unit.
With the optional IR remote control, it is possible to start build in programs.
，Specifications，
Voltage supply:
Max. power consumption:
Signal-Input :
Signal Output :
Casing:
Ambient temperature:
Dimensions:
Weight:
Specifications are subject to change.
MBN GmbH, Balthasar-Schaller-Str. 3,
5 - 24 VDC.
Maximum possible current 15 A
360 VA
DMX 512-A / RDM
Digital output
Power supply 5-24 VDC, with max. 6x 2,5 A
Metal case for operation in dry rooms (IP 30)
-10 C° ... 45 C°
127 mm x 86 mm x 25 mm (L x W x H)
ca. 0.30 kg
