To help ensure safe and reliable operation, use only genuine Hilti spare
parts and consumables. Spare parts, consumables and accessories
approved by Hilti for use with the product can be found at your local
Hilti Store or online at: www.hilti.group.
6.1 Replacing the supply cord
DANGER
Risk of injury! Risk of electric shock.
▶ The product may be serviced and repaired only by authorized, trained
personnel! This personnel must be specially informed of any possible
hazards.
If it is damaged, the supply cord has to be replaced.
Comply with the country-specific regulations for electrical safety.
1. Unplug the charger's supply cord from the power outlet.
2. Pull the rubberized foot out of the cover and remove the securing screw
exposed by removal of the rubberized foot.
Materials
Torx screwdriver T10
®
3. Flip the cover open.
4. Take a photo or draw a sketch so that you will be able to recall the
routing and conductor-to-terminal assignment of the supply cord.
5. Carefully depress one of the terminal clips with a flat screwdriver to
release the conductor. Disengage the conductor from the terminal clip.
Repeat this step for the second conductor and then remove the faulty
power cord.
