Operating manual

INSTALLATION - USING THE PRODUCT

Only experienced persons, authorised by the manufacturer, may carry out the installation. During installation, ensure that the power source is

disconnected from the mains. Series or parallel power source connections are not allowed. It is recommended to use the welding cables supplied with

the unit in order to obtain the best performance.

DESCRIPTION

The AUTOPULSE is a «synergic» semi-automatic welding machine, ventilated for welding (MIG or MAG). This machine is recommended for welding

steel, stainless steel, aluminium and the brazing. Its adjustment is quick and easy with its «synergic» mode.

DESCRIPTION OF THE EQUIPMENT (I)

Cable gland (mains cable)

On/Off switch

Gas connector T1

Gas connector T2

Gas connector T3

Cylinders support

Reel supports 1, 2 et 3

Wire feeder motor

Switch for purge-gas and wire feeding

HUMAN-MACHINE INTERFACE (HMI)

Please read the Human Machine Interface (HMI) which forms part of the equipment's user literature.

HMI

POWER SWITCH

• The 400 V model is supplied with a 16 A plug, type EN 60309-1, and should only be used in a three-phase 400 V (50-60 Hz) four-wire electrical

installation with a grounded neutral conductor.

• The 208/240 V model is supplied without a plug and should only be used in a three-phase 200-240 V (50-60 Hz) four-wire electrical installation with

a grounded neutral.

The effective absorbed current (I1eff) is indicated on the equipment, for maximum operating conditions. Check that the power supply and its protection

(fuse and/or circuit breaker) are compatible with the current required in use. In some countries, it may be necessary to change the plug to allow use

at maximum conditions.

• The 400V model is designed to operate on 400V +/- 15% electrical voltage. It will go into protection if the supply voltage is less than 330Vrms or

greater than 490Vrms. (a fault code will appear on the keypad display).

• The 208/240V model is designed to operate on 220V - 15% +20%. It will go into protection if the supply voltage is less than 185Vrms or greater than

270Vrms. (a fault code will appear on the keyboard display).

• It is switched on by turning the on/off switch (2 - FIG 1) to position I, and off by turning it to position 0. Warning! Never switch off the power supply

when the machine is under load.

CONNECTING TO A POWER SOURCE

The machine can work with generators as long as the auxiliary power matches these requirements:

- For the 400 V model: The voltage shall be alternating, its RMS value shall be 400V +/- 15%, and its peak voltage shall be less than 700V,

- For the 208/240 V model: The voltage shall be alternating, its RMS value shall be 220V - 15% +20%, and its peak voltage shall be less than 375V,

- The frequency must be between 50 and 60 Hz.

It is imperative to check these requirements as several generators generate high voltage peaks that can damage these machines.

USING EXTENSION LEADS

All extension leads must be of a suitable length and width that is appropriate to the equipment's voltage. Use an extension lead that complies with

national safety regulations.

SETTING UP THE REEL
