8.20 Schnittstellen

8.20.1 Daten

DVI
Pin Signalbelegung
1
TMDS Data 2-
2
TMDS Data 2+
3
TMDS Data 2 Shield
4 -
5 -
6 DDC Clock
7
DDC Data
8 -
9
TMDS Data 1-
10
TMDS Data 1+
11
TMDS Data 1 Shield
12
-

8.20.2 Remote Control

RS232 In
1
2
3
RS232 Out
1
2
3
Barco - OverView D Serie - Doc-3353-0 - Benutzerhandbuch - Revision 05 - Aug 2005
6
1
-
TXD
RXD
6
1
-
RXD
TXD
Pin Signalbelegung
13 -
14
-
15
Ground (+5, Analog /V Sync)
16
-
17
TMDS Data 0-
18
TMDS Data 0+
19
TMDS Data 0 Shield
20
-
21
-
22
TMDS Clock Shield
23
TMDS Clock +
24
TMDS Clock -
9
5
4 -
5 GND
6 -
9
5
4 -
5 GND
6 -
____________________________________________________________________
8. Technische Daten
7 -
8 -
9 -
7 -
8 -
9 -
