Room / liquid temperature:
Set point
Suction pressure, suction gas temperature:
Set point
Fig. 1: Capacity control with frequency inverter (FI) compared to on/off and stepped mechanical regulation
Also observe the following technical documents
• ESB-100 : Operating Instructions hermetic scroll compressors ESH7
• ESB-110 : Operating Instructions hermetic scroll compressors ELH7, ELA7
• ESB-130 : Operating Instructions hermetic scroll compressors ORBIT 6 and ORBIT 8
• CB-110 : Operating Instructions VARIPACK – external BITZER frequency inverters
2

Safety

Authorized staff
All work done on the products and the systems in which they are or will be installed may only be performed by
qualified and authorised staff who have been trained and instructed in all work. The qualification and competence
of the qualified staff must correspond to the local regulations and guidelines.
Residual risks
The products, electronic accessories and further system components may present unavoidable residual risks.
Therefore, any person working on it must carefully read this document! The following are mandatory:
• relevant safety regulations and standards
• generally accepted safety rules
• EU directives
• national regulations and safety standards
Example of applicable standards: EN378, EN60204, EN60335, EN ISO14120, ISO5149, IEC60204, IEC60335,
ASHRAE 15, NEC, UL standards.
