A. Construction and characteristics
Transportable terrace/garden heater with tank housing
Casing in steel with powder-coating or in stainless steel.
Gas hose connections with metal clamp (screw caps for Germany)
Heat emission from reflector
B. Specifications
Use propane,butane or their mixtures gas only.
Max. wattage: 13000 watts
Min. wattage: 5000 watts
Consumption:
APPLIANCE CATEGORY:
TYPES OF GAS:
GAS PRESSURE:
OUTLET PRESSURE
OF REGULATOR:
Using the proper regulator according to outlet pressure of regulator as showed in the table above.
C. Table of injector
APPLIANCE CATEGORY:
TYPES OF GAS:
GAS PRESSURE:
TOTAL HEAT
INPUT (Hs): (Qn)
INJECTOR SIZE:
The marking， for example， 1.88 on the injector，indicates that the size of injector is 1.88mm
The hose and regulator assembly must conform to local standard codes.
Regulator outlet pressure should meet the corresponding appliance category in B. Specification.
The appliance requires approved hose in 1.4m length.
I
3+(28-30/37)
Butane Propane
28-30mbar 37 mbar
30mbar 37 mbar
I
3+(28-30/37)
Butane, propane
Butane Propane
or their mixtures
28-30mbar 37 mbar 30 mbar
13kW (945g/h)
1.88 mm for main burner
0.18 mm for pilot burner
www.sunred.nl
I I
3B/P(30) 3B/P(50)
Butane, propane Butane, propane
or their mixtures or their mixtures
30 mbar 50mbar
30 mbar 50mbar
I I
3B/P(30) 3B/P(50)
Butane, propane
or their mixtures
50mbar
1.55 mm for main burner
0.18 mm for pilot burner
I
3B/P(37)
Butane, propane
or their mixtures
37mbar
37mbar
I
3B/P(37)
Butane, propane
or their mixtures
37mbar
1.65 mm for main burner
0.18 mm for pilot burner
