1. n
1.1 g
enerAl notes on sAfety
This operation manual is applicable for the machine USK
15-R. The machine may only be handled by personnel
who are qualified. Hold power tools by insulated gripping
surfaces when performing an operation where the cutting
tool may contact hidden wiring or its own cord. Contact
with a «live» wire will make exposed metal parts of the tool
«live» and shock the operator.
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future
reference.
1.2 u
se of the mAchine for PurPoses for
which it is intended
The machine is destined for the grinding and polishing of
metal with flap wheels, plastic non-woven brushes and
abrasive belts without the use of water. The machine is
designed exclusively for a 2-hand application.
1.3 i

ncorrect use

All uses other than those described under section
1.2 are regarded as incorrect use and are there-
fore not admissible.
1.4 ec
declArAtion of conformity
Otto Suhner GmbH of Trottäcker 50, D-79701 Bad Säck-
ingen, hereby declares under sole responsibility that the
product with the serial or batch no. (see reverse side) com-
plies with the requirements under the Directive 2014/30/
EU, 2006/42/EC, 2011/65/EU. Applied standards: EN ISO
12100, EN 60745, EN 55014-1, EN 55014-2, EN 61000-3-
2, EN 61000-3-3. Document Agent: R Ackermann. D-Bad
Säckingen, 02/2016.
R. Ackermann/Managing Director
2. c
2.1 P
rior to tAKing the mAchine into serVice
Before connecting tool to a power
source, be sure the voltage sup-
plied is the same as specified on
the name plate of the tool. The power sup-
ply should not vary more than 10% above or below the
voltage indicated on the nameplate. Check grinding tool
prior to use. The grinding tool must be mounted centrally
and positioned against the limit stop. The maximum al-
16
S
oteS on afety
ommiSSioning
lowable speed of the tool and of the chuck may not be
exceeded under any circumstances. Observe national
regulations. Remove safety guard.
2.2 t
AKing the mAchine into serVice
Preselect speed with adjusting wheel according to speed
table.
-1
Level 1: 6800 min
-1
Level 2: 8100 min
-1
Level 3: 9600 min
During operation never exceed the speed which
has been matched to the grinding tool specifica-
tions!
2.2.1 t /t
urn on urn off
The switch must be in the OFF position. To turn the ma-
chine on, push the ON/OFF switch toward the front unteil
it clicks in. Press the ON/OFF swith to trigger the blocking
and the machine shuts down.
2.3 r
Ating dAtA
Power voltage
Power Input 230/240V // 120V
Power Output 230/240V // 120V
No-load speed
Max. tool Ø
Pince de serrage Ø max.
Sound pressure level EN 60745
Noise emission level
Vibration EN 60745
Weight w/o cable
Protection class
-1
Level 4: 11100 min
-1
Level 5: 12500 min
-1
Level 6: 14500 min
230/240V/120V, 50/60Hz
1530W // 1340W
1000W // 800W
-1
6800-14500 min
55mm
12mm / 1/2"
86dB(A), K=3dB
97dB(A), K=3dB
2 2
5.3m/s , K=1.5m/s
2.9kg
II
