Helicopter Parameters

Length
Height
Weight
Main Rotor Diameter
Tail Rotor Diameter
Battery Specifications
Flight Time
Main Brushless Motor
Brushless Tail Motor

Battery Charging

1� Connect the USB cable to a computer USB port or a power adapter�
2� Connect the USBs other end (Type-C plug for Android) to the battery for charging�
3� During charging, the current battery level indicator will flash, and all our lights will
remain solid when charging is complete�
4� Disconnect the charging connection after charging is complete�
5� Note: It is recommended to use a 5V 2A adapter for charging, as it
28
352 mm
120 mm
383 g
328 mm
70 mm
7,4V 1200mAh 25 C
8-10 Min
2507
1204
