Product Description - Concept OV2116 Bedienungsanleitung

EN

PRODUCT DESCRIPTION

1 Flap
2 Handle
3 Casters
4 Air humidity indicator
5 Air outlet
6 Control panel
7 Air inlet
8 Water tank
9 Pre-filter, activated carbon filter
10 Outlet for continuous drainage
5
11 Back cover
12 Power cord
4
9
10
11
12
66
1
2
3
6
7
8
OV2016 | OV2116
INSTALLATION
In order for the dehumidifier to work efficiently, the recommended
distance must be observed, as shown in the figure.
If the operating noises of the dehumidifier interfere with TV or
.
radio, place the unit at least 70 cm from the device
OPERATION
DEFROSTING
• Frost may form on the inside of the dehumidifier. The appliance
is therefore equipped with an automatic defrost function.
• If the appliance is located in a room with a temperature between
5 and 12 °C, the automatic defrosting will start every 30 minutes.
• If the appliance is located in a room with a temperature between 12 and 20 °C, the automatic defrosting will start
every 45 minutes.
• The dehumidifier stops the operation temporarily while defrosting.
• Do not disconnect the plug from the socket and do not turn the unit off until defrosting is done.
• This type of dehumidifier is not suitable for lowering humidity to very low level (about 30 %).
• The model is suitable for removing unpleasant moisture in everyday life and as an auxiliary device for drying wet
laundry. It is not suitable for lowering humidity to very low levels.
CONTROL
Control description
Power button
Press the button to turn the appliance on. Press again to turn the appliance off.
Next to the power button there are 3 LED indicators.
When the appliance is switched on, the "Operation" LED indicator lights up. If the
water tank is full and needs to be emptied, the appliance will stop working and the
"Tank full" LED indicator will light up. When the appliance switches to automatic
defrosting, the "Defrost" LED indicator lights up.
OV2016 | OV2116
EN
67
