Connecting the power cord (1)

Fuse holder
Black
≠
+
Black/white
Hide-away unit
Yellow
To terminal always supplied
with power regardless of
ignition switch position.
Black (ground)
To vehicle (metal) body.
Center speaker
Fig. 3
