S-610 to S-920
10
S-500
11
3.

FUNCTIONS OF THE MULTIPORT VALVE

CONSTRUCTION & RÉNOVATION
Normal position of the valve. The water coming from the pump passes
FILTRATION :
from the top to the bottom of the filter and then returns to the pool.
The water coming from the pump is directed to the waste outlet without
WASTE :
passing through the filter.
No water circulation in this position. Make sure that the pump is never
CLOSED :
run while in this position.
Tighten the ring moderately.
Fit the o-ring into its groove on the lid. Fit the lid into
position. Tighten the ring moderately.
