Fig. 4:
A= Automatic
Move the upper switch to position "A" for
maintenance-free and non-maintenance-free
batteries.
N= Normal
Move the upper switch to position "N" only for non-
maintenance-free batteries.
Fig. 5:
N= Normal
Move the lower switch to position "N" for charging
with normal charging current.
S= Fast
Move the lower switch to position "S" for charging
with a higher charging current.
Figure 6:
First connect the red charging cable to the positive
pole of the battery.
Figure 7:
Then connect the black charging cable to the
bodywork of the vehicle away from the battery and
the petrol pipe.
Figure 8:
After the battery has been connected to the charger,
you can connect the charger to a socket supplying
230V~50Hz. Do not connect it to a socket that
supplies any other mains voltage.
Important. Charging may create dangerous
explosive gas and therefore you should avoid spark
formation and naked flames whilst the battery is
charging. There is a risk of explosion!
Figure 9:
Calculating the charging time
The charging time depends on the charge status of
the battery. If the battery is fully discharged, the
approximate charging time can be calculated using
the following formula:
Battery capacity in Ah
Charging time/h =
Amp. (arithmetic charging current)
24 Ah
Example = = 9,6 h max.
2,5 A
12
03.12.2010 9:58 Uhr Seite 12
A high initial current, approximately equal to the
rated current will flow in a normally discharged
battery. As the charging time increases, the charging
current will fall.
Old batteries for which the charging current does not
fall are suffering from a defect, such as a cell short
circuit or ageing damage.
Figure 10:
A high charge can only be identified by measuring
the acid density using an acid tester. Note! Gases
are released during the charging process (bubbles
will form on the surface of the battery fluid). It is
essential that you ventilate the rooms well.
Acid density values (kg/l at 20°C)
1.28 Battery charged
1.21 Battery semi-charged
1.16 Battery discharged
Figure 11:
Pull the plug out of the socket.
Figure 12:
First disconnect the black charging cable from the
bodywork.
Figure 13:
Then release the red charging cable from the
positive pole on the battery.
Figure 14:
Screw or push the battery stoppers back into position
(if there are any).

6. Overload cut-out

Figure 15:
The integral flat fuse protects the equipment from
polarity reversal and short circuits. If the fuse suffers
a defect it must be replaced by a new fuse with the
same amp value. If you wish to replace the flat fuse,
first pull the mains plug out of the socket and remove
the charger clamps from the battery. In the event of a
thermal overload, an automatic circuit breaker will
stop the charging process. After a cooling break it
will cut in again automatically.
