Installation Guide
8 . Mount back plate direct to wall or on wall box .
9 . Locate hooks at top of front part into top of back
plate and lower into position and tighten retaining
screw .
2 . Dimensions and Wiring
Dimensions, see fig . 4 . Wiring diagram, see fig . 5 .
3 . RF Pairing
1 . Ensure power to RX1-S receiver is switched on and
batteries are inserted into thermostat .
2 . Press and hold M button on thermostat for 6 sec-
onds until display changes to show setting options .
3 . Release and press M button until setting option 10
is shown .
4 . Press > button to change setting to 01 . RF aerial
icon will flash to indicate thermostat is in learn
mode .
5 . Press both PROG and CH buttons on RX1-S until
button LEDs flash .
6 . If pairing is successful RF icon on thermostat will
stop flashing and remain on .
7 . If pairing is not successful try moving thermostat to
alternative position and retry .
