after just a few minutes, this indicates that
the battery capacity is low. The battery needs
replacing.
Calculating the charging time (Fig. 3)
The charging time depends on the charge status
of the battery. If the battery is fully discharged,
the approximate charging time up to approx. 80%
charged can be calculated using the following
formula:
Battery capacity in Ah
Charging time/h =
Amp. (charging current)
The charging current should be 1/10 to 1/6 of the
battery capacity.
5.4 Error LED (Fig. 2 / Item C)
The error LED will fl ash (light up) in the following
cases:
•
If you have selected the wrong charging vol-
tage (12V) for a 6V battery. The equipment
fully charges the 6V battery and automatically
detects afterwards that the wrong charging
voltage was selected.
•
If the voltage of the battery is less than 3.5
V or more than 15 V. The battery is either un-
suitable for charging or is defective. It is also
possible that other battery errors or faults can
mean that the battery cannot be charged.
•
If the terminal clamps are connected to the
battery terminals with the wrong polarity. The
protection against swapped poles ensures
that the battery and charger do not get da-
maged. Remove the charger from the battery
and start the charging process from the be-
ginning again.
•
If there is a short-circuit between the two ter-
minal clamps (the metal parts of the clamps
come into contact with each other). The pro-
tection against short-circuits ensures that the
battery and charger do not get damaged.
5.5 Finishing charging the battery
•
Pull the plug out of the socket.
•
First disconnect the black charging cable
from the bodywork.
•
Then release the red charging cable from the
positive pole on the battery.
•
Important! In case of positive earthing, first
disconnect the red charging cable from the
bodywork and then the black charging cable
from the battery.
•
Screw or push the battery stoppers back into
Anl_CE_BC_1_M_SPK9.indb 14 Anl_CE_BC_1_M_SPK9.indb 14
GB
position (if there are any).
Important! If the mains plug is pulled out but the
charger cables are still connected to the battery,
the charger will draw off a small amount of elec-
tricity from the battery. We therefore recommend
that you always completely remove the charger
from the battery when not in use.

6. Overload cut-out

The charger is equipped with electronic protec-
tion against overload, short circuit and swapped
poles. One or more fi ne fuses are also fi tted. If the
fuse suff ers a defect it must be replaced by a new
fuse with the same amp value. If necessary, ple-
ase contact our customer service center.
7. Maintenance and care of the
battery
•
Ensure that your battery is always fitted se-
curely.
•
A perfect connection to the cable network of
the electrical system must be ensured at all
times.
•
Keep the battery clean and dry. Apply a thin
coating of grease to the connection terminals
using an acid-free, acid-resistant grease
(Vaseline).
•
Check the level of the acid in batteries that
are not maintenance-free versions approxi-
mately every 4 weeks and top up with distilled
water if necessary.
8. Cleaning, maintenance and
ordering of spare parts
Danger!
Always pull out the mains power plug before star-
ting any cleaning work.
8.1 Cleaning
•
Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
•
We recommend that you clean the device
immediately each time you have finished
- 14 -
