exit the grade alert mode, simply press the beeper switch or turn the power off. When
the unit is turned back on using the Power switch only, it will be in the normal opera-
ting mode.
Rod Clamp
1. Captive Rod Clamp Screw - attaches to
3 1
4
the back of detector.
2. Alignment Points - help secure and align
rod clamp to detector.
2
3. Reference Indicators - points are alig-
ned with the detector's on-grade loca-
tion for accurate grade rod readings.
4.Clamping Screw Knob - Secures clamp
5
to rods and staffs by moving the trave-
ling jaw.
5. Traveling Jaw - moving jaw grips tightly to rods.

Care and maintenance

Detector Cleaning: Do not wipe dust or dirt off the detector reception window or
display windows with a dry cloth or other abrasive material as scratching could
occur, reducing visibility through these windows. A soft cloth and mild soap and
water are effective. The unit may be submerged under water or sprayed with a low
pressure hose if necessary. Do not use any other fluids other than water or glass-
cleaner, as they may attack polymer components.
Intended Uses of Detector
The laser detector is designed and suitable for detecting a rotating laser beam.
Prohibited Uses
- Operation without instruction.
- Operation other than the intended uses.
- Opening the detector, except the battery compartment.
- Modification or conversion of the detector.
14
