DJI Three-Channel Follow Focus
Usage
Press the power button on the left side of the remote monitor to power on the remote monitor and
the follow focus. The remote monitor provides power to the follow focus. Once powered on, the
follow focus icon
is viewable in the upper left corner of the remote monitor. The follow focus is
successfully connected and ready for use.
To use the follow focus with the remote monitor, the video transmission system of the
remote monitor must be set to Control mode.
24.0V
100
CH1
CH2
Focus Control
The DJI Three-Channel Follow Focus supports marking a pair of limit points and multiple focus
points, which is convenient for quick and precise focusing.
To mark limit points or focus points, first switch the focus mode of the lens to MF (Manual
Focus).
Limit Points
Mark Limit Points
Mark a pair of limit points for the rotation range of the focus knob to limit the focus range of the lens.
To mark the limit points:
1. Turn the focus knob to the first limit point (such as Point A).
2. Press the LIMIT button once, and the first green icon
remote monitor.
3. Turn the focus knob to the second limit point (such as Point B).
4. Press the LIMIT button again, and the second green icon
the remote monitor.
4
User Guide
28.9M
WB
5600K
ND
Clear
A001C016
08:02:16:06
SS 1/200
IRIS
F2.8
EI
640
60'
ft
30'
20'
15'
12'
10'
8'
7'
6'
5'6
5'
4'6
4'
3'6
3'
2'9
2'6
A001C016
2'3
will show on the MF readings of the
will show on the MF readings of
A
1
2
3
B
