OPERATING INSTRUCTIONS DT 100 SERIES

DT 100 / DT 102 • DT 108 / DT 109
Thank you for selecting the DT 100/102 dynamic studio
headphone or the DT 108/109 dynamic headset. Please take
some time to read carefully through this operating instructions
before setting up the equipment.

Design Features

DT 100 / DT 102
The DT 100/102 are fully enclosed dynamic studio head-
phones with excellent ambient noise attenuation. They are
ideal for use in broadcasting, film and recording studios.
The DT 100 is a double-sided headphone while the DT 102 is the
single-side version.
The headband and earphone cushioning has been carefully
designed for maximum comfort during long periods of listening.
The connecting cables to the ear monitors run safely in the
headband and the main connecting cable is terminated on one
side with a multi-pin connector.
DT 108 / DT 109
The DT 108/109 are the same as the DT 100/102 head-
phones, with the addition of a dynamic hypercardioid
microphone. The DT 108/109 headset is used for intercom and
talkback systems as well as other applications where a dynamic
microphone headset is required.
The DT 109 is a double-sided headset while the DT 108 is the
single-side version.

Connection

The DT 100/102 studio headphones and the DT 108/109
headsets are packed with connecting cable, depending upon
your specification. For further connecting cables, please refer to
"Optional Accessories".
The K 100.00 connecting cable is built using a tinsel-conductor
cord. This type of conductor resists repetitive bending without
breaking, yet special care must be taken when making solder
joints to connectors. Wherever possible it is recommended to
fit crimped brass sleeves to the conductors and then solder the
sleeve to the connector. If direct solder connections have to be
