With each speed, the respective LED lights up.
Speed 1 LED L1
Speed 2 LED L2
Speed 3 LED L3
Intensive speed LED L4 (flashing).
Intensive speed is timed. Standard timing is 5', after which
the hood switches to speed 3.
To deactivate the function before the time expires, briefly
press T2; the hood will switch to speed 3.
To switch off the motor, press and hold key T2 for 3".
T4= Sensor ON/OFF. Activates or deactivates the VOC
sensor function.
By pressing the key, the VOC function is activated and LED
L5 becomes blue. When the VOC sensor function is
enabled, the motor must be switched off (if it was
previously ON). The hood will switch on at the most
suitable speed based on the fumes detected by the sensor
the hood is equipped with.
T5= Operating status indicator
VOC sensor calibration
The calibration of the sensor lasts about 5 minutes; press
T4 to switch on the hood at speed 1 (LED L5 on steady),
while LEDs L1, L2, L3 and L4 start flashing cyclically.
Calibration is complete when LEDs L1, L2, L3 and L4 go
out, followed by an acoustic signal (beep).
During calibration, it is only possible to switch the lights on
and off.
Calibration is necessary to allow the sensor with which the
hood is equipped to work correctly and can be:
automatic: each time the hood is reconnected to the mains
(e.g. the first time it is installed or after a power failure).
manual: to be performed when automatic operation is
unsatisfactory and when normal environmental conditions
persist in the kitchen.
Manual calibration is activated by pressing and holding key
T4 for 6".
Hob selection
To use the VOC function in the best way possible, it is
necessary to select the correct type of hob (gas - induction
or electric).
With the hood and the VOC sensor off, simultaneously
press T1 and T4 until an acoustic signal (beep) is emitted,
release the keys and when either T2 or T3 is pressed
again, the desired hob can be selected according to the
following diagram:
LED 1: gas hob
LED 2: electric hob
LED 3: induction hob
The selected key will remain lit to indicate that a selection
has been made; after 10 seconds, the key will flash briefly
to indicate that the selection made has been recorded.
Note: after resetting the hob type, to a type other than the
Default one or the previous one, an automatic calibration of
the VOC sensor will start.
Grease filter warning
After 40 hours of operation, LEDs L1 and L5 start flashing.
When this warning appears, it means that the installed
grease filter needs to be washed.
To reset the warning, press and hold key T2 for 3".
Carbon filter warning
After 160 hours of operation, LEDs L2 and L5 start
flashing.
When this warning appears, it means that the installed
carbon filter needs to be replaced.
To reset the warning, press and hold key T3 for 3".
In standard mode, the carbon filter warning is not
active.
If the hood is used in the filter version, it is necessary to
enable the carbon filter warning.
Carbon filter warning activation:
Switch the hood OFF and simultaneously press and hold
keys T2 and T3 for 3" (if LED L2 flashes, it means that the
carbon filter is NOT active), press key T3 to activate the
carbon filter warning function. LEDs L2 and L5 are steady,
wait 10" after which the function is activated followed by
an acoustic signal (beep).
Carbon filter warning deactivation:
Switch the hood OFF and simultaneously press and hold
keys T2 and T3 for 3" (if LED L2 is steady, it means that
the carbon filter is active), LEDs L2 and L5 are steady,
press key T3 and LED L2 will start flashing, wait 10" after
which the carbon filter warning function is deactivated
followed by an acoustic signal (beep).
MAINTENANCE WARNINGS
• Cleaning: For cleaning, simply use a cloth moistened
with neutral liquid detergents. Do not use cleaning tools or
instruments.
For product maintenance, see the images at the end
of the installation marked by this symbol.
• Anti-Grease Filter: The metallic anti-grease filter
must be cleaned once a month with non-aggressive de-
tergents, manually or in a dishwasher on a short wash at
low temperatures. To remove the anti-grease filter, pull
the spring release handle.
• Carbon filter (for filter version only): The car-
tridge must be replaced at least every four months. It
CANNOT be washed or regenerated. As indicated in the
drawings section: remove the anti-grease filters, apply a
carbon filter on each side and attach it to the product. Put
the anti-grease filters back in place.
• Washable activated carbon filter (for filter
version only):
The carbon filter can be washed every two months (or
when indicated by the filter saturation system - if included
