supervised. •The room must have sufficient ventilation
when the product is used at the same time as other
appliances burning gas or other fuels. •The product must be
cleaned frequently both inside and out (AT LEAST ONCE A
MONTH); always follow the instructions given in the
maintenance manual. •Failure to comply with the rules
indicated for cleaning the product and replacing/cleaning
the filters may result in the risk of fire. •It is strictly forbidden
to cook food on the flame under the product.• WARNING:
•When the hob is on, the accessible parts of the product
may become hot. •Do not connect the product to the
electrical power supply until the installation is complete.
•The regulations laid down by local authorities must be
strictly followed with regard to the technical and safety
measures to adopt for fume extraction. •The extracted air
must not be conveyed through the same ducts used to
extract the fumes generated by gas combustion or other
types of combustion products. •Do not use or leave the
product without appropriately installed lamps, as this may
result in the risk of electric shock. •The product must
NEVER be used without the grille correctly fitted. •The
product must NEVER be used as a support surface unless
expressly indicated.
INSTALLATION SAFETY
•Use the fixing screws supplied with the product only if
suitable for the surface; otherwise purchase the correct
type of screws. •Check for accessories (e.g. bags
containing screws, warranty certificates, etc.) inside the
product (placed there for transport reasons). If there are
any, remove them and keep them safe. • WARNING:
Failure to install screws and fasteners in accordance with
these instructions may result in electrical hazards. •The
exhaust pipe is not supplied and must be purchased. •The
diameter of the exhaust pipe must be equivalent to the
diameter of the connecting ring. •For installation of the
product on the hob, respect the height indicated in the
drawings •The minimum distance between the surface of
the container supports on the cooker and the lowest part of
the range hood must not be less than 50 cm (not less than
57 cm only for Australia and New Zealand) for electric
cookers and 57 cm for gas or mixed cookers. •If the
installation instructions of the gas cooker specify a greater
distance, take it into account.
ELECTRICAL CONNECTION SAFETY
•The mains voltage must correspond to the voltage
indicated on the label found inside the product. •If it
features a plug, connect the product to a socket that
complies with current standards, located in an area
accessible even after installation. •If it does not feature a
plug (direct connection to the mains) or the plug is not
located in an accessible area, even after installation, apply
a standard double pole switch that ensures complete
disconnection from the mains in category III overvoltage
conditions, in accordance with the installation rules. •The
product features a special power cable; if the cable is
damaged, contact the Service Centre for a replacement.
END-OF-LIFE DISPOSAL
This device is marked in compliance with the Eu-
ropean Directive 2012/19/EC - UK SI 2013
No.3113, Waste Electrical and Electronic Equip-
ment (WEEE). Make sure that this product is di-
sposed of correctly. The user helps prevent po-
tential negative consequences for the environ-
ment and for health.
The symbol on
documentation indicates that this product should not be
treated as household waste but should be handed over at a
suitable collection point for the recycling of electrical and
electronic equipment. Dispose of it in accordance with local
regulations for waste disposal. For further information
about the treatment, recovery and recycling of this product,
please contact your local authority, the collection service
for household waste or the shop from where the product
was purchased.
REGULATIONS
Equipment designed, tested and manufactured in
compliance with safety regulations: EN/IEC 60335-1; EN/
IEC 60335-2- 31, EN/IEC 62233. Performance: EN/IEC
61591; ISO 5167-1; ISO 5167-3; ISO 5168; EN/IEC
60704-1; EN/IEC 60704-2-13;EN/IEC 60704-3; ISO 3741;
EN 50564; IEC 62301. EMC: EN 55014-1; CISPR 14-1; EN
55014-2; CISPR 14-2; EN/IEC 61000-3-2; EN/IEC
61000-3-3.
OPERATION
Please note! This hood features an automatic operation
system (see the paragraph "VOC sensor calibration").
Calibration occurs automatically each time the hood is
reconnected to the electrical network (e.g.: the first time it is
installed after a blackout). It can also be performed
manually (see the paragraph "VOC sensor calibration -
manual").
During calibration, which lasts 5 minutes, the controls will
flash and only the light button can be used.
T1 T2
T1= LIGHTS ON/OFF.
T2= Motor OFF or Reduce speed (e.g.: from 4 to 1).
From whichever position the hood is in, pressing the key for
3" switches off the motor.
T3= Increase suction speed.
Press T3 to switch the hood on at speed 1, keep pressing
the key to increase the motor speed from speed 2 to
intensive. Press and hold the key for 3" to automatically
activate INTENSIVE speed.
6
the product or accompanying
L5
L1 L3
L2 L4
T3
T5
T4
