5.3

timer settings on remote control

Timer: Displays current day, time, and week.
Press to enter or confirm timer settings.
Settings: Press to move to next step (use
with Timer button). Press to confirm week
timer.
Back: Press to clear timer settings. Press to
return to the previous step (use with Settings
button).
Up and down: Use with Settings button.
LCD Screen
Weekday:
Mon., Tues., Wed., Thurs., Fri., Sat., Sun.
Time Display:
Current Time / Timer From 00:00 to 24:00
NOTE: 00-12:00 is AM / 13:00 - 24:00 is PM

5.3.1 set current day and time

1. Press once. When "MON" (Monday) begins flashing, use
plete the setting.
2. When the hour digits begin flashing, use
3. When the minute digits begin flashing, use
ting.

5.3.2 set ON/OFF time and temperature on a weekly cycle

1. Press once. When "MON" (Monday) begins flashing, use
plete the setting.
note:
The timer can only be adjusted in 30-minute intervals (i.e. 00:00 - 00:30; 00:30 - 01:00, etc.).
2. When --:-- begins flashing, use
to complete the setting. Press
3. When "18" begins flashing, use
note:
If the temperature was previously set, those digits will be shown instead of "18".
4. When --:-- begins flashing, use
to complete the setting. Press
to select the current hour. Press OK to complete the setting.
to select the current minute. Press OK to complete the set-
to select the desired hour and minutes to turn on the heater. Press OK
at any time to clear the digits and shut down "ON" timer.
to select the desired temperature to turn on the heater for Monday.
to select the desired hour and minutes to turn off the heater. Press OK
at any time to clear the digits and shut down "OFF" timer.
operating instructions
NOTE: The func-
tions can only be
adjusted when the
related letters or
digits are flashing.
NOTE: Calibrate
the timer to cur-
rent time before
the weekly set-
tings.
to select current day. Press OK to com-
to select current day. Press OK to com-
