Diamond – Quickstart

Word clock

If you have an external word clock connected to the Diamond, set the CLOCK
17
switch to Word. In Source position the Diamond derives its clock from the
choosen digital source.

DIP switches

You can use the DIP switches on the rear panel to make the following basic
18
settings:
DIP switch 1: OFF = The level of the RCA analog output is adjusted with the
DIP switch 1: ON = The level of the RCA analog output is fixed (Unity Gain).
DIP switch 2: OFF = The level of the XLR analog output is adjusted with the
DIP switch 2: ON = The level of the XLR analog output is fixed (Unity Gain).
6
volume control.
volume control.
