Diamond – Quickstart
Start up
1
Read the security advices on page 8!
Make sure that the selected mains voltage of the Diamond is according to the
2
mains voltage of your region.
Make sure that the mains switch on the rear of the Diamond is set to Off
3
(Off = O / On = I).
4
The standby switch on the front panel has to be set to
Connect the supplied power cord to the Diamond and to an appropriate mains
5
socket outlet.
If the supplied power cord does not match your mains socket outlet, please contact your dealer.
6
Turn off all devices you wish to connect to the Diamond.
Connect the outputs of your digital sources (e.g. Mac, PC or CD Player) to the
7
digital inputs of the Diamond. Please use appropiate audio cables (AES, USB,
coaxial, optical).
For Windows® computers download the latest driver from spl.audio/diamond and have it installed. Macs, iPhones
and iPads do not require a driver since the USB port is Apple-Class compliant.
Optionally connect the output of your word clock source to the word clock input
8
of the Diamond. Please use an appropiate cable (BNC, 75 Ω).
Connect audio cables (XLR, RCA) between Diamond and a following amplifier or
9
active loudspeakers.
Depending on the setting of the DIP switch (see page 6), the level of the analog outputs (RCA, XLR) have a fixed
level (Unity Gain) or is adjusted by the volume control.
1 Cables not included in the scope of delivery.
