If everything is installed correctly and checked, then the gyro gain should be set to
about 30% for the first flights.
Operation MODE I (DIP-Switch 2 in Position OFF)
The gyro gain is controlled directly from the transmitter (AUX channel), and can be
adjusted from 0% to 100% gain. However for the first flight we recommend starting
with about 30%-40% gain. Once in the air, increase the gain slowly until the model
starts to wag out, then reduce the gain until it stops.
If you are experienced with that function, you can adjust the dynamic pot and try to
increase the gain.
Operation MODE II, HEADING (DIP-Switch 2 in Position ON)
If the gyro shall be used in HEADING, set DIP switch 3 in position ON. With this MODE
the gyro offers both Modes, Standard- and HEADING-Mode. In HEADING-Mode the
gyro holds the position of the stabilised axis as long as the stick is in centre position.
During stick movement, the gyro has no function, the stick is directly working with the
controls, after the stick has reached the centre position again, the gyro recognises the
last position of the model as its new position to hold on. In MODE II the AUX channel
changes as shown. Minimum sensitivity is in 0-position, maximum sensitivity in
Standard-Mode is at one max. position of the sensitivity channel, max. sensitivity of
HEADING-Mode is at the other end of the sensitivity channel. In that way it can be
switched between Standard-Mode and HEADING-Mode. HEADING will be indicated
with LED twinkling 3 times.
In HEADING it also should be started with 30%-40% sensitivity. Once in the air,
increase the gain slowly until the model starts to wag out, then reduce the gain until it
stops. If you are experienced with that function, you can adjust the dynamic pot and
try to increase the gain.
During HEADING, you can say there is no stick trimm available, because a given trimm
amount will lead to a a turn of the model. Therefore trim the model during use of
Standard-Mode, then switch to HEADING. The trim position of Standard-Mode will be
overtaken to zero position of the tail during HEADING. Any further trim movement
during HEADING will start to turn the helicopters tail.
In HEADING-Mode, the gyro controls the angle speed in conjunction to the stick
position, therefore any servo signal out of the centre position will result in turning the
model.
Note: A slow drifting of the servo's neutral position during HEADING is normal. During
use it will be compensated.
Technical data's
• Voltage range
• Consumption
• Weight
• Size
• Temperature range
• Servo-limiter by Software
• 3-level, self learning temperature drift compensation
• NORMAL/REVERSE-Switch
• 8-Bit Microprocessor, Clock speed 22 MHz, 4096 Bit
• Programmable Servo throw and centre position
• Adjustable dynamic without PC
• LOCK-ON-Function (Heading Lock) indicated by LED
• Low voltage drop compensation for max. 2 seconds, no problem with switching ON
procedure
•
LED-Monitor
We wish you much fun with the
airplanes.
French
FUZZY professional V2
Piezo le gyroavec la fonction de Heading pour des modèles de vole
Description
Nous nous réjouissons que vous vous ayez
comprendre exactement la diversité de fonction complexe, lisez s'il vous plaît cette description
complètement avant que vous commenciez par l'utilisage.
FUZZY pro
Le gyro de Piezo
sert à la stabilisation des modèles de vol. Le gyro reconnaît par son
logiciel intelligent, avec l'électronique de microprocesseur et le détecteur de Piezo chaque
mouvement du modèle autour de l'axe de gyro et produit l'un de ce mouvement lde Servo
opposé. Le gyro est branchée en plus purement entre servo pour cet axe et le récepteur. Les
axes qui sont conduits avec 2 Servos peuvent aussi être stabilisés. L'effet peut être choisi dans
deux modes d'opération. Le MODE I correspond à un amortissement (Normalement) au
mouvement d'idée. Le MODE II correspond à un effet d'appui (Heading) contre des mouvements
d'idée qui influent du dehors sur un modèle.
La sensitivité de le gyro peut être choisi librement au moyen du canal supplémentaire de
l'émetteur et être adapté avec cela au modèle et à la sensation d'impôt du pilote. En outre, est
commuté avec le canal de sensibilité aussi entre les deux modes d'opération, ou DE et Est
tourné le commutateur par.
Les résultats les meilleurs sont obtenus lors de l'application par Servos rapides. Nous
recommandons fondamentalement l'application de Futaba-Servos, puisque ces Servos
9
3,3 Volt - 9 Volt
about 45 mA
about 30 Grams
48 x 39 x 15 mm
-10° - +50° Celsius
Fuzzy pro
and a lot of more performance for your
pour FUZZY pro
incontestablement. Pour
