Bühler technologies AGF-VA-350 Bedienungs- Und Installationsanleitung Seite 16

Dimensions (inch)
Technical Data
Temperature max.
Pressure max.
Dead volume
Weight approx.
Please indicate with order
Filter
Part no. Type
41 35 999 AGF-VA-350-T, housing
41 35 9993 Mounting bracket
90 07 700 Plug
Filter elements
Part no. Type
41 35 G002 GF2
41 35 G005 GF5
41 35 G010 G10
0
0.39
1.38
2.36
IN
NPT 1/4
6.02
6.65
302°F
5076 psi
18 ml with filter element
1.76 lb
Material
Seal Viton FEP covered
1.4301
1.4571
Material
glass fibre / epoxy resin
glass fibre / epoxy resin
glass fibre / epoxy resin
ø0.28
OUT
NPT 1/4
Bypass
NPT 1/4
Material
Housing
Filter elements
Seal
Pore size max. Temperature
2 µm 302°F
5 µm 302°F
10 µm 302°F
3.15
2.17
Ø1.97
Ø1.42
SS 316 L
See table
Viton FEP covered
we reserve the right to amend specification
