Technical Data - Bühler technologies AGF-VA-350 Bedienungs- Und Installationsanleitung

Dimensions in mm

Technical Data

Temperature max.
Pressure max.
Dead volume
Weight approx.
Please indicate with order
Filter
Part no. Type
41 35 999 AGF-VA-350-T, housing
41 35 9993 Mounting bracket
90 07 700 Plug
Filter elements
Part no. Type
41 35 G002 GF2
41 35 G005 GF5
41 35 G010 G10
0
10
35
60
IN
NPT 1/4
153
Bypass
NPT 1/4
169
150°C
350 bar
18 ml with filter element
0.8 kg
Material
Seal Viton FEP covered
1.4301
1.4571
Material
glass fibre / epoxy resin
glass fibre / epoxy resin
glass fibre / epoxy resin
ø7
OUT
NPT 1/4
Material
Housing
Filter elements
Seal
Pore size max. Temperature
2 µm 150°C
5 µm 150°C
10 µm 150°C
80
55
Ø50
Ø36
SS 316 L
See table
Viton FEP covered
we reserve the right to amend specification
