Translation of the original operating instructions
1.
About this documentation
The following information only describes the product. Any information on how
to use the product is only an example and a recommendation. Catalog
information is not binding. The information given does not release the user from
the obligation of own judgment and verification. Our products are subject to a
natural process
of wear and aging.
© All rights reserved by Bosch Rexroth AG, including for the registration of
industrial property rights. This document may not be reproduced or distributed
to third parties without our consent.
The title page depicts a sample configuration. The actual product may vary from
what is shown in the illustration.
The original operating instructions were written in German.
Validity of documentation
Read these instructions and the required and supplementary documentation
3 842 358 820, "General safety instructions for electrotechnical installation
of MPS components" before working with the product or putting it into
operation.
www.boschrexroth.com/mediadirectory
2.
Safety instructions
Observe the safety instructions from the manual 3 842 358 820, "General
safety instructions for electrotechnical installation of MPS components."
CAUTION: To reduce the risk of fire, electric shock, or injury to persons:
• a) Use only insulated staples or plastic ties to secure cords;
• b) Route and secure cords so that they will not be pinched or damaged when
the cabinet is pushed to the wall;
• c) Not intended for recessed installation in ceilings, or soffits; and
• d) The National Electrical Code (NEC) does not permit cords to be concealed
where damage to insulation may go unnoticed. To prevent fire danger, do
not run cord behind walls, ceilings, soffits, or cabinets where it may be
inaccessible for examination. Cords should be visually examined periodically
and immediately replaced when any damage is noted.
Intended use
• Only use the lamps in dry and clean interiors.
• Do not use lamps in the direct vicinity of chemical emissions
(e.g. oil mist, soldering fumes) or of sources of dust.
Fuse
EU ≤ 16 A, USA/CAN ≤ 15 A (see table
Improper use
Any use other than that described as intended use is considered to be improper,
and therefore not permitted. Bosch Rexroth AG is not liable for damage resulting
from improper use. The user alone bears any risks associated with improper use.
Improper use includes:
• Use in environments with high levels of condensation (humidor)
or in chemical emissions.
• Light arrangements that force the user to stare into the LED for a longer
period of time.
• Use without sufficient protection against mechanical effects.
• Use as shelf for objects.
• Use through which the electrical operating tools used are not in compliance
with the national regulations.
• Non-commercial use.
3.
Scope of delivery
For the system light and fastening material, see figure
Note: The lamps are installed ready for use.
4.
Product description
The system lights SL 12 LED eco (wide) are used for the glare-free lighting of
workstations.
Housing materials: steel sheet, painted (light grey), plastic, aluminium
Identification of the product
Done via the material number (3 842...) on the nameplate (see figure
5.
Assembly
Observe the safety instructions from the manual 3 842 358 820, "General
safety instructions for electrotechnical installation of MPS components."
Make sure that the electrical operating tools used are in compliance with
the national regulations.
Assembly of SL 12 LED eco (wide)
The assembly steps are shown in figure
Lighting strength
The lighting strength depends on the arrangement of the system lights SL
and the ambient light, also see table
Electrical installation of SL 12 LED eco (wide)
1.
Make sure that the installation is only performed by persons with the relevant
electrotechnical knowledge and experience (see manual 3 842 358 820).
6
, Imax (A))
1
.
2
4
.
3
.
2.
Install the cables only with the power switched off.
Use the appropriate cable; see table
3.
For the installation, see figure
Please note that a max. 25 system lights may be operated in series or per
fuse (for the fuse, see table
For the series connection, see manual 3 842 358 820, "General safety
instructions for electrotechnical installation of MPS components".
6.
Commissioning/operation
• Only start up the product if you have read and understood the required
and supplementary documentation 3 842 358 820, "General safety
instructions for electrotechnical installation of MPS components".
• Make sure that all connections are either being used or are covered. Make
sure that all bolted connections and plug-in connections are properly seated.
• Only start up a product which has been completely installed.
System lights can be switched on/off using a socket strip with an on-switch/
off-switch or the main switch for the working area.
7.
Removal and replacement
The light source of this luminaire should only be replaced by the
manufacturer, a service technician commissioned by the manufacturer or a
person with comparable qualifications.
8.
Disposal
• Dispose of the product in accordance with the regulations in your country.
9.
Upgrading and modification
• Do not modify the product.
• The Bosch Rexroth warranty only applies to the configuration as delivered,
and to approved upgrades. The warranty shall expire following a modification
or upgrading that is beyond the scope of the wiring described in the
supplementary documentation 3 842 358 820, "General safety instructions
for electrotechnical installation of MPS components".
10. Technical data
Lamp
Equipping
Service life
Mains connection
Power consumption
Protection type
Nominal ambient temperature
L [mm]
H x T [mm]
Weight
(lamp + mounting)
Light color/color temperature
Risk group
).
11. Explanation of symbols
Declaration of conformity. The product fulfills the requirements of the
relevant EU directives.
Special disposal regulations apply,
see chapter 8 „Disposal".
6
.
5
.
6
).
SL 12 LED eco
SL 12 LED eco
(wide)
LED
>50 000 h
100...240 V~; 50...60 Hz
max. 16 A
EU:
11,5±0,5 W
EU/
12,5±0,5 W
USA/
CAN:
IP 20 EN 60529/IEC 60529
0 °C bis +40 °C, non-condensing,
Class 1, Dry location only
580
40 x 80
2 kg
850/5000 K (Kelvin), cool white,
CRI ≥ 80
Photobiological safety: DIN EN 62471
RG 1: "No hazard in consideration of
normal human behavior"
3/15
870
2,8 kg
