Merax MS199769 Benutzerhandbuch Seite 31

No. Description
1 Monitor
2 Mid wire
3 Upright Tube
4 Tension control
5 Cross Pan Screw M5*50
6 Curved Washer D5
Curved Washer φ8.5*φ20*2
7
8 Spring Washer D8
9 Inner Hexagon Pan Screw M8*20
10 Mid handlebar
11 Handlebar foam
12 Seat cushion
13 Seat tube
Flat washer φ8
14
15 Nylon nut M8
16L L pedal
16R R Pedal
17 Rear bottom tube
18 Rear Feet cap
19 Square Bolt M8*73
20 Domed Nut M8
21 Hole End Cap
22 Front bottom tube
23 Feet cap
24 Main frame
25 Tension control down wire
26 Flywheel
27 Flywheel axis
28 Bearing support
29 Bearing 6001RS
30 Bearing board
31 Hexagon Bolt M6*9
Flat Washer φ6.5*φ16*1.5
32
33 Hexagon Bolt M6*15
34 Magnetic board
35 Magnetic board axis
36 Spring Washer D6
37 Snap ring D12
38 Magnetic Grip
39 Black Magnetic
40 Tension spring
Qty No.
1 41 Cross Pan Screw ST3*10
1 42 Hexagon Nut M6
1 43 Hexagon Bolt M6*60
1 44 Hexagon Nut
1 45 Washer
1 46 Tow-groove Nut
8 47 Ball frame
10 48 Ball bowl
4 49 Tri-groove Nut
1 50 Washer
2 51 Belt disk
1 52 Cross Drown Screw ST4.2*20
1 53 Belt
Flat Washer φ10.5*φ20*2
3 54
3 55 Nylon Nut M10
1 56 Idler sleeve
1 57 Idler
1 58 External Hexagon Bolt M10*45
2 59 Hexagon Round-head Screw M6*30
4 60 Cross Pan Screw ST4.2*20
4 61 Cross Pan Screw ST4.2*16
2 62 Sensor
1 63 Union crank
2 64L L cover
1 64R R cover
1 65 Hole cap
1 66 Knob
1 67 Seat sleeve
2 68 Round Inner Tube cap
2 69 Inner Hexagon Pan Screw M8*30
2 70 Handlebar Cover
6 71 Screw M5*10
4 72 Pulse
Flat Washer φ6*φ12*1
4 73
1 74 Pole
1 75 Adjustable Horizontal Tube
2 76 Square Inner End Cap
2 77 Open-groove Seat sleeve
1 78 Seat sleeve
Flat Washer φ8.5*φ20*1.5
4 79
1
31
Description Qty
5
3
1
2
1
1
2
2
1
1
1
2
1
1
1
1
1
1
EN
1
7
5
1
1
1
1
2
1
1
2
2
1
2
2
2
1
1
2
1
1
1
