Installation
Installing the support rod
Remove the hex screw and lock washer from the support rod. Insert the support
rod into the back of the mixer so that the holes line up for the hex screw. Secure
with hex screw and lock washer and tighten with hex key.
Clamp the mixer to a Cole-Parmer stand on a stable, level surface (see Safety
Instructions).
Connect mixer to supplied power supply. Connect power supply to a grounded
electrical outlet.
Impeller attachment
Insert the impeller shaft into the open chuck and adjust the impeller to the desired
height. The hollow shaft allows the impeller shaft to come through the top of the
mixer if necessary. Tighten the chuck's outer ring by hand and then secure with
the chuck key.
CAUTION:
Operating a freely rotating impeller shaft through the top of the mixer is not
safe. Do not allow the impeller shaft to touch or extend through the rubber
gasket while the motor is powered on. The gasket is for sealing purposes
only.
Environmental Operating Conditions
The
Reversing Digital mixer
Indoors
1. Altitudes up to 2000 m (6500 ft).
2. Temperatures from 5ºC to 40ºC (41ºF to 104ºF).
3. Maximum relative humidity 80% for temperatures up to 31
linearly to 50% relative humidity at 40ºC (104ºF).
4. Pollution degree 2 in accordance with IEC 664.
must operate in the following conditions:
5
C (88
F) decreasing
o
o
