Technical Data

Model Number
Speed Range
Functions
Speed Readout Accuracy
Maximum Torque
Input To Power Supply
Electrical Output from Power
Supply to Mixer
Mechanical Output Power
Weight - Mixer Only
Weight - Power Supply
Maximum Volume
Maximum Viscosity
Molded Front Housing
Cast Back Housing
Combined Housing
Keypad
Stir Light
Power Cord Length
Adjustable Chuck

General Operating Instructions

Make sure the mixer is securely mounted as specified in the installation
instructions. Ensure the mixing paddle or impeller is securely attached to the
desired position.
The mixer is now ready for use to mix liquids and liquid/solid solutions.
Appropriate impeller and container specifications must be determined by the
operator, ensuring that all safety instructions are followed.
50004-00
40 - 2010 rpm
Countdown Timer
Clockwise
Counter Clockwise
xRx Agitation
± 1 rpm or ± 3% of reading, whichever is
greater, 4 digits
90 Ncm, (127 in-oz)
AC 100-240 volts, 50/60 Hz, 2.5 amps
(Must use supplied power supply.)
DC 24 volts, 3.75 amps
1/15 hp, 50 watts, (Brushless DC Motor)
3.0 kg (7 lbs)
0.6 kg (1.2 lbs)
25 litres (6.6 US gallons)
20,000 cps - e.g. chocolate syrup
Flame retardant, chemical resistant, high
impact nylon. Recyclable (PA).
Epoxy coated zinc
Splash Proof (IP42)
Waterproof, chemical resistant polyester.
5 Ultra Bright LEDs, 100,000 hour life.
183 cm (6 ft) from mixer to power supply-
DC.
183 cm (6 ft) from power supply to wall-AC.
Fits onto 13 mm (33/64 in) dia output shaft
of mixer. Adjusts up to 10 mm (3/8 in).
