HMS L5704 Bedienungsanleitung Seite 12

PARTS LIST
No.
1
Main Frame
2
Rear Stabilizer
3
Front Stabilizer
4
Backrest Frame
5
Seat Frame
6
Backrest Adjustable Bracket
7
Seat Adjustable Bracket
8
Backrest
9
Seat
10
Bolt M10x100mm
11
Bolt M8x90mm
12
Bolt M6x40mm
13
Bolt M8x15mm
14
Nylon Nut M10
15
Nylon Nut M6
16
Washer M10
17
Washer M8
18
Bushing
19 Adjustable Knob
20 Square Inner Cap 50mm
21 Handle Grip
22 Small Rubber Ring
23 Big Rubber Ring
24 End caps
25 Handwheel
26 Washer M6
Description
- 12 -
Q'Y
1
1
1
1
1
1
1
1
1
2
4
2
16
2
2
4
20
4
2
4
1
1
1
4
2
4
