1.3.2. Removing/installing the battery

Before remove/install the battery, please disconnect the charger.
Step 1. Turn the key in the battery
lock counter-clockwise.
Step 1. Insert the battery into the
down tube. Ensure the lock is facing
the bottom bracket
Step 2. Using your key, press the pin
located on bottom of down tube
Step 2. Press the battery upwards until the button springs clicks into place. Check the
battery is firmly in place by making sure that there is no gap between the frame and
the battery and that the battery cannot be removed by pulling the battery cap lever.
Step 3. Pull the battery pulling handle
until the battery out of the frame
Attention: Dropping the battery into
the down tube will break the
charging connector.
Attention: Always remove the key
before riding.
