1.3.1. Adjusting the Saddle height

The correct saddle height is reached when your leg is almost
straight when putting the ball of your foot on the pedal. The crake
arms are thereby aligned vertically.
To check the saddle height, sit on the bike trial the height via a
ride or leaning against a wall.
To change the saddle height, proceed as follows:
Step 1. Loosen the screw of the seat post clamp
with the Allen key provided in the Modmo
Toolbox until the seat post can move freely
4mm
6
YO UR B I C YCLE
Step 2. Adjust to the desired height
Important Information:
The seat post clamp is tightened enough when the seat post
cannot be turned or when it no longer slides down into the seat
tube under your weight.
Attention:
Do not clamp the seat post above the minimum insertion
height or you will be at serious risk of injury. The seat post is a
part of electrical system. Do not remove the seat post from the
frame. It will damage the wiring system and could result in an
electrical fault. In case of damage, please contact Modmo
Customer Service or a Modmo Service Centre in your area.
Step 3. Retighten the screw to a torque of
5-12 Nm. Do not over-tighten the bolt as it
can cause it to break
