2.6. Gates Carbon Drive System:
Gates User Manual
The chain is an element that will naturally relax by the efforts it
undergoes. During the life of the bike it will be necessary to
control its tension regularly.
Using two 15mm flat wrenches, loosen the nuts on the rear hub.
If you have chain tensioning screws, refer to paragraph 3.
Otherwise, pulling the rear wheel toward the rear, tension
your chain.
Using a 3 or 4mm Allen wrench, tighten the two chain tensioning
screws gradually until an acceptable voltage is reached (see
below). Through the unique adjustment of each chain tensioner
screws you can center the tyre between your stays.
You can then tighten the clamping nuts of the rear hub using
two 15mm flat wrenches tightening with 30 Nm. torque.
When properly tightened, the chain must be able to move
vertically by about 10mm when pressed in the middle of the
chain.
Important Information:
Please be aware that use of the Gates Carbon Drive system in ice and snow,
can lead to the teeth of the pulleys becoming clogged. This can lead to the
belt being pushed off of the pulley, or lifted up and ratcheting over it. Both of
these possibilities could reduce the safe operation of the system. For this
reason, the use of the bike in snow and ice should be avoided. The use of the
system in mud should also be avoided for the same reasons
Please refer to Gate's Carbon Drive:
https://www.gatescarbondrive.com/~/media/files/gcd/owners-manuals/englis
h-owners-manual-gates-carbon-drive.pdf?la=en

2.7. Brake System

Your Modmo Saigon E-Bike is equipped with hydraulic disc
brakes that will stop you quickly and safely when needed.
Use both brakes simultaneously for safe braking.
2.8. Display Error
If there is something wrong with the electronic control
system, the display will show the error code automatically.
The following is the definition of the main error codes
24 Motor Hall Defect
30 Abnormal Communications
Display return to normal only after problem being fixed and
bike will not run before fixing the problem.
