Condensation tray
Note!
The position numbers of the spare parts differ from those describing the
positions of other parts mentioned in this operating manual.
TERMINATE SWITCH
SEE FIG 1.
WITH
BRACKET TO LOOM ASSY
10
LOOM ASSY
TERMINAL BLOCK
PART OF LOOM ASSY
ON
OFF
230V
VERSION
No. Item number
1 SD512050
2 7140000928
3 7140000353
4 SD073150
7 7130000918
9 SA356403
17 SD369350
B - 16
7
1
O
1 2
DUAL VOLTAGE
VERSION
Spare part
drip tray
defrost control stat
run capacitor 30 μF 440 V
hard start cap/relay
rotary switch 2 pole on/off
loom assembly AX
pipe insert bung
2
Operating Manual – Construction dryer TTK 400
3
4
HARD START
CAPACITOR
IF FITTED
EN
