RF connection completed:
Valid rainfall reading appears
RF connection failed:
"- - - -" stops flashing & stays on the rainfall display
4. Mounting the rain gauge
- Before mounting the rain gauge, be sure the rain gauge & main unit are within the effective
transmission range and batteries are installed.
Hold the base of the rain gauge flat against the mounting surface then use a level to make sure
-
the rain gauge (as it rest on the mounting surface) is horizontally level.
- Use a pencil to trace the inside of the mounting holes on the base of the rain gauge to mark the
screw locations.
Drill a hole in the center of each marked location and insert the supplied plastic screw plugs
-
Hold the rain gauge against the mounting surface so the holes on the base are aligned with the
-
plugs, then thread the supplied washer head screws into each hole and use a screwdriver to
tighten them.
DAILY, WEEKLY, MONTHLY & ACCUMLATED RAINFALL
Daily rainfall reading located inside the white line of the display
Press [RAIN MODE] repeatedly to switch between the different modes
- Daily rainfall mode when "DAILY" icon appears
- Weekly rainfall mode when "WEEKLY" icon appears
Monthly rainfall mode when "MONTHLY" icon appears
-
Total rainfall mode when "TOTAL" icons appear
-
In daily, weekly, monthly or total rainfall display, hold [RAIN MODE] for 3 seconds to clear the
corresponding rainfall display readings to zero
Press [RAIN UNIT] to change the rainfall unit between mm and inch
IN/OUT TEMPERATURE
Temperature reading is located on the bottom of the display
Press [LIGHT/CHANNEL] to select indoor "IN", Ch1, Ch2, Ch3 and auto-channel scrolling "
display modes.
Press [C/F] button to select temperature unit between C/ F.
COLOR BAR GRAPHS
The color graphs are designed as an intuitive way to gauge the weather at a glance.
The left color bar graph represents the respective indoor or outdoor temperature. As the temperature
"
