User manual // EH Pro Mini / EH Pro Mini 1200 P (Speed) Flash Head
Flashlight and modeling lamp
The modeling light of the connected EH Pro Mini flash
1:
head is switched on and off using switch 1. The flash
ON / OFF
power and modeling light options are set using power
control and modeling lamp switches of the connected
generator.
9
EH Pro Mini flash heads do only need very few main-
tenance by the user. The unit should be dry cleaned from
dust from time to time. Before cleaning switch the power
pack off and separate the flash head from the power pack.
Caution:
Under no circumstances is any part of the equipment
to be opened. The equipment is not user-serviceable
and there is dangerous high voltage. In the event of
difficulty notify your dealer.

Replacement of fuses

2
In case of a broken fuse for the halogen modeling lamp 2,
replace fuse only when the power pack is switched off and
the flash head separated from power pack.
Attention:
Never repair or bridge fuses. For replacement of
fuses please only use fuses with the required value
(please see table below). A wrong fuse may cause a
bursting of the halogen modeling lamp.
Flash head
230 V~ operation
EH Pro Mini (Speed):
120 V~ operation
EH Pro Mini (Speed):
Operation with Porty:
EH Pro Mini 1200 P (Speed):
34
All manuals and user guides at all-guides.com

Maintenance

Modeling lamp
650 W / 230 V halogen
300 W / 120 V halogen
60 W / 12 V halogen
HENSEL-VISIT GmbH & Co. KG
Fuse
4 AF
4 AF
5 AM
