User manual // EH Pro Mini / EH Pro Mini 1200 P (Speed) Flash Head
5:
Tilting head
30
All manuals and user guides at all-guides.com
Heating
Each flash head emits heat through its modeling light and
flash tube. This can heat parts of the lamp head up to a
dangerous level.
Further do not operate lamp heads and generators in the
near of inflammable objects. Therefore make sure that
generators and lamp heads are located far enough from
inflammable props to avoid inflaming them. Take care for
sufficient air supply and make sure that ventilation slots
of flash heads and generators are kept free.
Do not operate power packs or lamp heads unattended.
Due to the danger of overheating, the modeling light
should never be operated at full power for more than 20
minutes. Then adequate cooling should be provided for.
The modeling light should never be used for lighting up
the studio but only as assistance when focusing or
determining the light guiding and shadow details of the
flash.

Acclimatizing

When moving the EH Pro Mini flash head from one
climatic zone to the next, the appliance should stand in the
room, in which it will be operated, for some time before
starting it up. This prevents internal shortcuts caused by
eventually condensing water.

Positioning

EH Pro Mini flash heads are equipped with a tilting head 5.
The unit can be attached to a stand or pantographs by
using one of the two holes a. The head can be swivelled
round 360°. By tightening the knurl screw b the unit can be
fixed. The safety screw must be screwed into thread c.
Wing nut d guarantees for tilting up and down. To ensure
smooth movement please oil the thread if necessary.
Above the tilting head an umbrella holder e is integrated.
