INSTALLATION
The Phantom PH 90 lift door closer is suitable for DIN left and DIN right doors. The sense of
rotation is determined by the installation position of the axle.
The Phantom PH 90 can be installed in the door frame as well as in the door leaf.
The door closer is attached to the door using a bracket.
When attaching the operating arm, make sure it is still pretensioned (about 20°) even when the
door is closed. This assures the door will always close and stay securely closed.
With the Phantom PH 90 it is also possible to adjust the closing speed and the final latch (see
drawing).
Questions?
We'll be happy to help! Just contact us!
4
Installation instructions - Lift door closer Phantom PH 90
