Part List - Merax MS282323 Benutzerhandbuch

If any part is missing, distorted or broken when you receive the package, please consult your supplier in
time. With your order number we will send the replacement part to you as soon as possible.
Component
1. Bottom base x 2
4. Support frame x2
8. Backrest pipe
Screw Accessories
13. M8*70mm
12. Curved
bracket x4
18. M8*40mm
Allen bolt x4
23. Knob x4

Part List

2. Connecting pipe
(With curved bracket)
5. Connecting pipe
(With flat bracket)
9. Backrest
12. Elastic cord x2
14. Washer x10
Allen Bolt x8
19. M6*30mm 20. M8*16mm bolt x2
Allen bolt x4
25. Open end Wrench
24. Clamping nut x4
3. Bottom handlebar x 2
6. Parallel bar x2
10. Handlebar
15. Lock nut x22
16. M8*40mm
carriage bolt x8
21. M8*80mm
Allen bolt x2
26. Allen wrench
EN
7. Arm pad x2
11. Extension pipe
x2
17. Flat bracket x2
22. Curved washer x4
27. M6*16mm Allen
bolt x12
Pre-attached to arm
pads (No.7) & backrest (No.9)
15
