FitEngine 09552 Bedienungsanleitung Seite 25

Part Designation
No.
12-3 Cross-head screw
13 Spanner 13 – 15
14 Allen key 5 mm
15 Spanner 17 – 19
16 Multifunctional tool (spanner with
cross-head screwdriver)
A-1 Allen bolt
A-2 Spring washer
A-3 Regular washer, fl at
A-4 Allen bolt
A-5 Allen bolt
A-6 Nut, self-locking
A-7 Carriage bolt
09552_Inlay_DE-EN-FR-ES-IT_A5_FE_V3.indb 25 09552_Inlay_DE-EN-FR-ES-IT_A5_FE_V3.indb 25
Number Dimensions
4 M5 x 10
1
2
1
1
2 M16*54 mm
2 Ø8*2t
10 Ø8*Ø16
2 M8*P1.25*20L
6 M8*P1.25*40 mm
10 M8
4 M8*P1.25*40mm
