3. Adjustment & Operation
3.1 Adjustment Sets (Fig.12, 13)
Locking Set
Diopter Ring
Left Coarse Focus Knob
Interpupillary Distance Indicator
Left Fine Focus Knob
Longitudinal Adjustment Knob
Transversal Adjustment Knob
Condenser Adjustment Knob
Aperture Diaphragm Adjustment Lever
Fig.12
Tension Adjustment Collar
Right Coarse Focus Knob
Right Fine Focus Knob
Brightness Adjustment Knob
Main Switch
Fig.13
