2. Assembly

2.1 Assembly Diagram

The following figure shows the installation sequence of the components. The number in the figure
shows the assembly steps.
★ Before installing, be sure every components is clean, do not score any parts or glasssurface.
10X Eyepieces
Digital Viewing Head
②
20X Eyepieces
WF20X WF20X
①
③
④
Objectives
Power Adapter
Main body
