tROUBLesHOOtInG

COnDItIOn
Front LED is not On
Green LED but no sound or low output
sound level
Intermittent operation (front panel led
transitioning from green to red)

sPeCIFICAtIOns

DesCRIPtIOn
Rated Output Power (RMS) into the
minimum impedance of 4 Ohms
Peak power
Rated impedance
Minimum load impedance
Model-Specific EQ
Input Sensitivity to 1W @ 50Hz
Input Overload (Both inputs driven)
Input Impedance
Low Pass Crossover range
Auto Turn On Input Sensitivity @ 50Hz
THD+N at 1W
THD+N at Rated Output Power
Signal-to-Noise ratio to 1W
Minimum AC Mains power requirements
Power consumption (Standby)
Height
Width
Depth
Weight
Features, specifications and appearance are subject to change without notice.
POssIBLe ReAsOn
• No power to the amplifier: The amplifier is not plugged into the power receptacle. Make sure power cord is
plugged into a properly working AC power outlet.
• No power to the amplifier: AC Mains power switch is set to Off. Make sure Mains power switch is set to On.
• No power to the amplifier: Main fuse is blown.
IMPORtAnt!
Always disconnect unit from the AC Mains before checking AC mains fuse section. The AC Mains fuse,
should not generally blow unless a malfunction has occurred. The fuse must be replaced only with the exact
type and rating of the fuse originally supplied and specified. If the fuse has been replaced but blows again
within a short time, disconnect all power immediately and contact your dealer for support.
• Input signal is not present or is at a very low input level; Check subwoofer level settings at the preamp or
processor.
• Volume control is turned down: turn the SDA-1700 front-mounted volume control clock-wise.
• Crossover control is set too low: Raise the crossover frequency by rotating the crossover control clock-wise.
• Output connections are shorted: Check for shorts in the loudspeaker cables.
• Amplifier is in thermal protection: Refer to the "Cooling Requirements" section of this manual. Look for
ventilation restrictions and/or high ambient temperature.
sPeCIFICAtIOn
700Watts
1500W
8Ohms per speaker output
4Ohms
1: Only for JBL SYNTHESIS SSW-4; 2: Only for JBL C82W
16.3mVrms +/- 1dB (Single input driven) Gain=41.7dB
≥ 2.0Vrms
> 10K Ohms
50-150Hz
Typical 10mV
< 0.3%
< 1%
> 65dBA
100-120VAC-50-60Hz Model: 700W, 5A
230VAC-50-60Hz Model: 700W, 3A
0.5W
3.50in (88.90mm)
17in (431.8 mm)
11.04in (280.3mm)
14Lb (6.35Kg)
