11. Place the container used to collect the descaler solution
empty under the cappuccino maker and coffee spouts (fig.
36).
12. Turn the hot water/steam dial to the I position to begin
rinsing. Hot water is delivered first from the cappuccino
maker, to continue and end with the coffee spouts.
13. When the water tank is completely empty, the
lights flash on the control panel. Turn the hot water/
steam dial to the 0 position.
14. Empty the container used to collect the rinsing water. Re-
move the water tank, replace the water softener filter (if
removed previously), fill the tank up to the MAX level with
cold water and insert in the appliance. The
light flashes.
15. Place the container used to collect the rinsing water empty
under the cappuccino maker;
16. Turn the hot water/steam dial to the I position. Rinsing
continues from the cappuccino maker only.
17. When it finishes, the
trol panel. Turn the hot water/steam dial to the 0 position.
18. Top up the water tank with fresh water to the MAX level
and put back in the machine.
Descaling is complete.
Please note!
• If the descaling cycle is not completed correctly (e.g. no
electricity) we recommend repeating the cycle.
• After descaling, it is normal for the grounds container
(A13) to contain water.

16. SETTING WATER HARDNESS

Descaling is necessary after a period of operation established
according to the water hardness set.
The machine is set by default for a hardness value of 4. The ma-
chine can also be programmed according to the hardness of the
mains water in the various regions so that the machine needs to
be descaled less often.

16.1 Measuring water hardness

1. Remove the "TOTAL HARDNESS TEST" indicator paper (C1)
from its pack (attached to the English instructions).
2. Immerse the paper completely in a glass of water for one
second.
3. Remove the paper from the water and shake lightly. After
about a minute, 1, 2, 3, or 4 red squares form, depending
on the hardness of the water. Each square corresponds to
one level.
steam
steam light flashes on the con-
and
16.2 Setting water hardness
1. Make sure the appliance is off (but connected to the
mains electricity supply and with the main switch in the
I position);
2. Press and hold the
onds. The
3. Press the
actual water hardness as measured by the indicator paper.
Level
1
4. Press the
confirm the selection.
The machine is now reprogrammed with the new water hard-
ness setting.

17. TECHNICAL DATA

Voltage:
Absorbed power:
Pressure:
Max. water tank capacity:
Size LxDxH:
Cord length:
Weight:
Max. beans container capacity:
This product is compliant with Regulation (EC) No.
1935/2004 on materials and articles intended to come
into contact with food.

18. DISPOSAL

The appliance must not be disposed of with house-
hold waste, but taken to an authorised waste separa-
tion and recycling centre.
17
Level 1
Level 2
Level 3
Level 4
button (B5) for at least 5 sec-
and lights come on together;
button (B3, on the left of the dial) to set the
Level Level
2 3
button (B8, on the right of the dial) to
220-240 V~ 50/60 Hz max. 10A
1.5 MPa (15 bars)
240x430x350 mm
Level
4
1450 W
1.8 L
1150 mm
8.9 kg
250 g
