User manual / Bedienungsanleitung

4. Operation controls

balance reference phono
Pic. 6: Front view of the
1
Select Input A / Input B
Allows you to easily switch between the connected tonearms with their respective settings.
If the device is in standby mode, this is also deactivated by selecting the respective input.
When you press the button, it starts flashing, signaling that the phono stage is starting up.
With music output, the button of the respective input lights up continuously.
2
Headphone output (separate for input A / input B)
Plugging in headphones will deactivate the rear panel outputs
3
Volume control / standby / mute function:
• The volume control allows you to adjust the gain simply by turning the wheel.
• To activate the „mute function" briefly press the button in the middle of the wheel.
The button of the respective input flashes.
• Press the button again to deactivate the „mute function". The button of the input is now
continuously lit again.
• To put the device into standby mode, press and hold the button for about 2-3 seconds.
The buttons for both inputs flash twice and then light up continuously again.
To play music again, select the respective input via „Input A / Input B".
To switch off the device completely when not in use for a long period of time and to
avoid unnecessary standby consumption, we recommend to switch off the main switch
on the back.
4
Receiver remote control
Made in Germany
1
2
4
1
3
2
Page / Seite 11
