Reset To Factory Settings; Technical Data; Temperature Unit - EWT FUTURE Bedienungsanleitung

10.4

Reset to factory settings

Resets all settings made by the user to the pre-set fac-
tory settings.
Hold down and


pears.
Press or to select the Y display. The symbol
 

flashes.
Press the ENTER key. All values are reset to the

factory settings. Time display appears.
Set the time and date.

10.5

Temperature unit

Display can be set to degrees Celsius and degrees
Fahrenheit.
Hold down the MENU key until ° C display flashes.

Press or to select ° C or ° F.
 

Confirm with the ENTER key.

NOTE
The temperature unit ° C is customary in most
European countries.
www.ewt.eu
until the Fr n display ap-

11. Warranty
This product is supplied with a two-year warranty
according to our terms of guarantee.
12. Note on disposal
Do not dispose of the unit with general
household waste. The device must be taken to
a local waste disposal plant.

13. Technical data

Model reference
Nominal voltage
Degree of protection
Dimensions (W x H x D)
Weight
Heat output
Nominal heat out-
put
Minimum heat
output (indicative)
Maximum contin-
uous heat output
Auxiliary electricity consumption
At nominal heat
output
At minimum heat
output
In standby mode
Type of control
Electronic room temperature controller with week program,
adaptive control of the heating start and operating time limit
Glen Dimplex Deutschland GmbH
Am Goldenen Feld 18
D - 95326 Kulmbach
2101/A
Future
1/N/PE, 230 V~, 50 Hz
IP24
300 x 405 x 120 mm
3,2 kg
P 2,0 kW
nom
P 1,0 kW
min
P 2,0 kW
max, C
el 0,0 W
max
el 0,0 W
min
el 0,5 W
SB
Tel.: +49 9221 709 700
Fax.: +49 9221 709 701
E-mail: info@gdhv.one
EN-9
