9.4. Tricera Handpieces
Figure 6: Tricera Autoclaveable Handpiece
DCO-1394
Effective Date: 12-JAN-2022
3
7
1
2
5
Figure 5: Veriflow (Top) and Exoflow (Bottom) Fluid Management Accessories
2
1
3
1. Plastic Cassette
2. Outflow Peristaltic Pump
3. Inflow from Saline Bag
4. Outflow to Suction Container
5. Outflow from Patient
6. Inflow to Patient
7. Inflow Pressure Diaphragm
8. Inflow Peristaltic Pump Tube
4
5
6
1. TPE Pump Tubing
2. Barb Lock
3. PVC Waste Tuing
4. Outflow Lumen
5. Barb Connector
3
6. Cassette Magnet
4
1. Buttons
2. Cable
3. Suction Connector
