1.4. Warranty
For the product warranty refer to the general terms
and conditions of sale.
The warranty covers only the replacement and
i
the repair of the defective parts of the goods
(recognized by the manufacturer).
GB
The Warranty will not be considered in the following
cases:
- Whenever the use of the device does not conform
to the instructions and information described in this
manual.
- In case of changes or variations made without
authorization of the manufacturer.
- In case of technical interventions executed by a non-
authorized personnel.
- In case of failing to carry out adequate maintenance.
1.5. Technical assistance
Any further information about the documentation,
technical assistance and spare parts, shall be
requested from: Calpeda S.p.A. (paragraph 1.2).

2. TECHNICAL DESCRIPTION

Control panel with protection for submersible drainage
pumps or for booster sets with surface pump, with
single-phase or three-phase motor, DOL.
Type
single-phase
QML/A 1 D 12A-FA
QML/A 1 D 12A-FA 20
QML/A 1 D 12A-FA 25
QML/A 2 D 12A-FA
QML/A 2 D 12A-FA 20
QML/A 2 D 12A-FA 25
QML/A 2 D 12A-FA 30-85 1÷12
QML/A 2 D 12A-FA 35-85 1÷12
Type
three-phase
QTL/A 1D 12A-FA
QTL/A 2D 12A-FA
QTL/A 3D 12A-FA
2.1. Intended use
The control panel allows two different modes of pump
operation: drainage or pressure mode.
2.2. Improper use
The device is designed and built only for the purpose
described in paragraph 2.1.
Improper use of the device is forbidden, as
is use under conditions other than those
indicated in these instructions.
Improper use of the product reduces the safety and
the efficiency of the device, Calpeda shall not be
responsible for failure or accident due to improper
use.
Do not use in ponds, tanks or swimming
pools or where people may enter or come into
contact with the water.
Page 18 / 92
Capacitor
Setting primary starting
A µF µF
1÷12 - -
1÷12 20 -
1÷12 25 -
1÷12 - -
1÷12 20 -
1÷12 25 -
30 85
35 85
Setting
A
1÷12
1÷12
1÷12
2.3. Marking
The following picture is a copy of the name-plate that
is on the external case of the pump.
1 - Type
2 - Supply voltage
3 - Current
4 - Rated power
5 - Code and Serial
number
6 - Protection
7 - Certifications
6
7

3. TECHNICAL FEATURES

3.1. Technical data
The electrical panel functions correctly under the
following power and installation characteristics:
IP protection: IP55
Supply voltage/ Frequency:
• 230V 1~ ±10% 50/60Hz (other voltages on request)
• 380-400V 3~ ±10% 50/60Hz (other voltages on request)
• Ambient temperature: -5 ÷ + 40 °C
• Relative Humidity: from 20 to 90% without
condensing
3.2. Operating conditions
Provide for enough space all around the control panel
for natural cooling.
Do not install the control panel in places
exposed to direct sunlight or near sources of
heat.
3.3. Construction
Standard construction
• Box in thermoplastic material
• Line selector switch with door-locking device
• Power line fuses
• Auxiliary circuit fuses
• Contactors
• Transformer
• MPS 3000 type electronic card with microprocessor
• Cable glands
• Connection terminals for remote alarm control
panel RA type or free voltage contact module MSP
• Interface for MPS 3000 electronic card
• Terminals board
• Capacitors (if present)
3.4. MPS 3000 electronic card
The functioning of the pumps is managed by the
MPS3000 electronic card that incorporates the
following functions:
• changes pumps at every pump arrest (Excluding
1 PUMP).
• changes working pumps after a time of uninterrupted
operation, settable at parameter UP05.
• automatic functioning test of the pumps after a
period of inactivity (with pumps in the automatic
functioning mode), settable at parameter UP06.
(Drainage – 1 pump)
• 2 float switches: one float switch for starting-
up and stopping the pump, one for the alarms
(maximum level is optional).
M004_REV06_ - Operating Instructions
Example plate pump
CALPEDA spA - Montorso - Vicenza - ltaly
Type QXXX X X XXXXX
Tipo
Mains
V 220/230 - 1 - 50/60 Hz
Alimen.
Output A XX + XX
max
Uscita
Motors kW XX - XX
Motori
Cod. 14054750000-17020006
IP 55
MADE IN ITALY
1
2
3
4
5
