INSTRUCTIONS FOR USE
f. To reduce the chances of patient tissue damage, ensure that patient does not
come in direct contact with hard surfaces.
g. To reduce the chances of skin maceration and shear, it is recommended that
Allen Ultra Comfort™ Covers be used between the patient and the pads.
h. To avoid injury to patient, ensure all supports are properly secured and locked
prior to loading a patient.
i. To avoid serious injury to patient, additional restraints must be used to securely
restrain the patient to the OR table prior to tilting the system.
j. To avoid serious injury to patient, before operating the table ensure the area
beneath/around the table is clear of objects that could obstruct or come in
contact with the patient or support platforms.
CAUTION:
a. Do not exceed safe working load shown in the product specification table
b. Damage may result if product is cleaned with bleach.
c. To prevent patient and/or user injury and/or equipment damage: all
modifications, upgrades, or repairs must be performed by an Allen authorized
specialist. Failure to comply may void warranty.

4.2 Product Specifications:

Mechanical Specifications
Product Dimensions
Document Number: 80028187
Version: C
A-71301 Chest Support w/ Pad: 17.4ʺ X 7.7ʺ X 4.1ʺ
(44 cm x 19.5 cm x 10.4 cm)
A-71312 Sling Support: 37.7ʺ X 26.25ʺ (95.7 cm x 66.6 cm)
A-71303 Small Hip w/ Pad: 8.5ʺ X 5.25ʺ X 9.2ʺ
(21.5 cm x 13.3 cm x 23.4 cm)
A-71305 Medium Hip Support w/ Pad: 7.5ʺ X 5.25ʺ X 9.7ʺ
(19 cm x 13.3 cm x 24.6 cm)
A-71307 Large Hip support w/ Pad: 10ʺ X 5.25ʺ X 11.7ʺ
(25.5 cm x 13.3 cm x 29.7 cm)
A-71309 and A-71311 Left and Right Thigh Supports w/ Pads:
4.7ʺ X 5.2ʺ X 8.9ʺ (12 cm x 13.5 cm x 22.6 cm)
