ENGLISH (Original instructions)
1-1. Switch trigger
1-2. Lock button
2-1. Lamp
3-1. Reversing switch
4-1. Action mode changing lever
SPECIFICATIONS
Capacities
No load speed (min
Blows per minute
Overall length
Safety class
• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
Intended use
The tool is intended for impact drilling in brick, concrete
and stone as well as for drilling without impact in wood,
metal, ceramic and plastic.
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and
can only be operated on single-phase AC supply. They
are double-insulated in accordance with European
Standard and can, therefore, also be used from sockets
without earth wire.
For European countries only
Noise
The typical A-weighted noise level determined according
to EN60745:
Sound pressure level (L
Sound power level (L
Uncertainty (K) : 3 dB(A)
Wear ear protection
Vibration
The vibration total value
determined according to EN60745-2-1:
Work mode: impact drilling into concrete
Vibration emission (a
Uncertainty (K) : 2 m/s
Work mode : drilling into metal
Vibration emission (a
Uncertainty (K) : 1.5 m/s
All manuals and user guides at all-guides.com
Explanation of general view
5-1. Side grip
6-1. Chuck key
7-1. Sleeve
7-2. Ring
8-1. Depth gauge
Model
Concrete
Steel
Wood
-1
)
Net weight
ENE039-1
ENF002-1
ENG102-2
) : 95 dB(A)
pA
) : 106 dB(A)
WA
ENG203-1
(tri-axial vector
2
) : 22 m/s
h,ID
2
ENG301-1
2
) : 3 m/s
h,D
2
HP1620/HP1620F/HP1621/HP1621F
The declared vibration emission value has been
•
measured in accordance with the standard test
method and may be used for comparing one tool
with another.
The declared vibration emission value may also be
•
used in a preliminary assessment of exposure.
WARNING:
The vibration emission during actual use of the
•
power tool can differ from the declared emission
value depending on the ways in which the tool is
used.
Be sure to identify safety measures to protect the
•
operator that are based on an estimation of
exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it
is running idle in addition to the trigger time).
EC Declaration of Conformity
We Makita
sum)
manufacturer declare that the following Makita
machine(s):
Designation of Machine: Hammer Drill
Model No./ Type: HP1620,HP1620F,HP1621,HP1621F
are of series production and
Conforms to the following European Directives:
98/37/EC until 28th December 2009 and then with
2006/42/EC from 29th December 2009
And are manufactured in accordance with the following
standards or standardised documents:
3
8-2. Side grip
8-3. Grip base
9-1. Blow-out bulb
16 mm
13 mm
30 mm
0 - 2,800
0 - 44,800
303 mm
2.0 kg
/II
Corporation as the
ENG901-1
ENH101-12
responsible
